FND-TSG125
Multi-layer Safety Protection to Cut Job-site Risks, Injuries and Downtime Loss The agitator automatically stops when the feeding door opens to prevent mechanical injury during material feeding. The trailer system is equipped with dual safety chains, electric brake and emergency brake, supporting towing speed up to 80km/h to avoid equipment falling-off during transit. The spray gun adopts safe low-voltage heating ≤75V and is detachable for maintenance. It protects operators and lowers losses caused by safety accidents. Low-position feeding port reduces workers’ physical burden.
2.Optimized Thermal-oil Interlayer & Special Combustion Chamber for Faster Heating and Less Material Waste The melting kettle features optimized thermal-oil interlayer requiring less thermal-oil filling than competing products, speeding up heating and cutting thermal-oil replacement cost. The 45-degree diagonal-flame combustion chamber avoids direct flame contact with kettle body. Indirect constant-temperature heating prevents sealant scorching and whole-batch material scrappage, saving your sealant cost. Dual digital LCD thermostat displays real-time temperature of thermal oil, sealant and hose for easy parameter control.
3.Submerged Maintenance-free Gear Pump, Trigger-on-demand Pumping to Extend Service Life and Reduce Spare-part Expense The bidirectional variable rigid gear pump is installed at tank bottom with protective mesh to block foreign objects for maintenance-free performance. The pump only runs when the spray-gun trigger is pulled, reducing mechanical wear and prolonging pump service life. Hydraulic solenoid valve adjusts output flow for on-demand material delivery and less overflow waste.
4.Full-hydraulic Drive & 5.5-meter Effective Working Radius to Minimize Machine Repositioning and Save Labor Cost Powered by Yanmar diesel engine with full-hydraulic drive and stepless speed change. The total hose length reaches 6.7m with 5.5m fully heated working radius. The hose features anti-twist protection, single-tube delivery without loop or valves for easy servicing. Operators can seal cracks over a wide zone without frequent machine relocation, boosting daily output under same manpower and cutting labor expenditure.
5.500L Large-capacity Tank Enables Long-hour Continuous Operation and Less Frequent Refilling The 500L tank melts 200kg sealant within 45minutes and supports 8-hour continuous melting of 1500kg sealant. It suits long-distance concentrated road maintenance. Less frequent refilling eliminates waiting downtime and keeps projects on schedule.
6.Built-in Lifting Arm for Multi-function Operation, Improving Equipment Utilization and Reducing Extra Procurement Cost The integrated lifting arm hoists auxiliary tools such as router, hot air lance, blower and vacuum cleaner. One main unit transports multiple accessories in one trip, eliminating separate trailer transport and cutting your investment in additional machines.
7.Torsion-suspension Heavy-duty Trailer Chassis for Stable Long-distance Transit and Harsh Site Conditions The single-axle torsion suspension axle has rated load capacity of 2420kg with vacuum tires for stable towing on bumpy job-site roads. It fits cross-zone scattered maintenance projects, minimizing transit breakdowns and schedule delays.
