XHS-50000
FND
1.Capable of spreading snow melting agent, road salt, sand, granular stones and other materials. Spreading width adjustable from 0.6 m to 12 m, suitable for narrow road maintenance and wide road de-icing operations.
3. Precision electronic dual speed control with safe and easy operation
Dual variable speed control system installed in the cab to separately adjust the rotation speed of auger and spinner disc. Equipped with explosion-proof and overload protection devices. Standard vibration motor prevents material caking and blockage, delivering stable discharging flow.
4. Large loading capacity and suitable for light-duty trucks
5m³ large-capacity hopper with maximum loading weight of 5700kg. Compatible with 3/4 ton and 1–4 ton light trucks. The spinner disc assembly can be quickly disassembled for easy cleaning and routine maintenance.
5. Complete configurations for night operation with high driving safety
Standard LED rear view lights and LED warning lights ensure good visibility for night operation under rainy, snowy and low-temperature conditions. Powered by high-torque DC 12V motor (24V optional). Stainless steel V-channel and polyester spinner disc feature excellent wear resistance.1.
Parameter | Specification |
Model | XHS-50000 Polyethylene Spreader |
Overall Dimensions | 4400mm (Length) × 1300mm (Height) × 1380mm (Width) |
Spreader Net Weight | 770Kg |
Hopper Volume | 5m³ / 5700kg |
Applicable Spreading Materials | Salt, Sand, Granular Stone, Snow Melting Agent |
Hopper Material | Polyethylene |
Feeding Mechanism | Internal Screw Auger Conveying with Adjustable Speed (Auger Outer Diameter: 16CM; Auger Pitch: 23CM) |
Maximum Feeding Rate | 0.06 m³ Per Minute |
Gearbox Reduction Ratio | 1:80 |
Discharge Motor | High-Torque DC12V (24V Optional) |
Spinner Disc | 36.8cm Polyester |
Spreading Width | 0.6–12 m |
V-Channel | Stainless Steel |
Adjustable Baffle | Polyester Material |
Auger Motor | 800W (12V/24V) |
Spinning Motor | 200W (12V/24V) |
Receiver Hook | Class 4 |
Spinner Assembly | Easy to Disassemble |
Control Unit | Dual Speed Control with Explosion-Proof Function and Overload Protection |
Minimum Truck Bed Length | 168CM |
Applicable Vehicles | 3/4 Ton, 1–4 Ton Light-Duty Trucks |
Vibration Motor | Standard Equipment |
LED Rear View Light | Standard Equipment |
LED Warning Light | Standard Equipment |
Control Mode | In-Cab Control |
1.Snow & Ice Removal for Industrial Parks and Scenic Areas
It is widely used in large industrial parks, logistics bases, tourist attractions and campus road networks as well as parking lots. Mixed deicing salt and anti-slip sand can be spread on branch roads and ramps to prevent vehicles and pedestrians from skidding.
Matching advantages: The net weight of the machine is only 770kg, bringing no burden to light trucks. The spinner assembly can be quickly disassembled for easy removal of residual sand and gravel. The in-cab control system enables one-person independent operation.
2.Emergency Snow Removal at Highway Toll Stations and Service Areas
Highway operation companies adopt this machine for ice removal on toll plazas, ramps and service area pavements. It replaces inefficient manual spreading and allows flexible switching between pure deicer and anti-slip sand spreading.
Matching advantages: The dual-speed independent control for auger and spinner disc realizes precise adjustment of discharge volume to avoid material waste. Equipped with overload and explosion-proof protection, the machine maintains stable performance during long continuous operations.
